10000 Liter SINOTRUK HOWO Oil Tanker Truck For Somalia
-1. SINOTRUK HOWO Oil Tanker Truck Detail.
The oil tanker truck is composed of a special vehicle chassis and an upper part. The upper part is composed of a tank body, a power take-off, a transmission shaft, a gear oil pump, a pipe network system and other components. The pipe network system is composed of oil pump, three-way four-position ball valve, two-way ball valve, filter screen and pipeline.
-2. SINOTRUK HOWO Oil Tanker Truck Specification.
|
Description |
Parameter value |
|
Product Name |
SINOTRUK HOWO Oil Tanker Truck |
|
Application |
For haulage oil, fuel, diesel, petrol etc |
|
Engine |
WD615.62, 266HP, EURO 2 |
|
Cabin |
HW76 cabin,with one bed, A/C |
|
Gearbox |
HW19710, 10F & 2R, with PTO, Manual Gearbox |
|
Front Axle |
1x9000kg, steering axle |
|
Driving Axle |
2x16000kg, driving axle |
|
Tire |
295/80R22.5, 6+1 pcs, Triangle brand |
|
Tanker Body |
10000 liter, 2 comdepartment |
|
Fuel Tank |
400L |
|
Loading Tons |
15-20 tons |
|
Max Speed |
75km/h |
|
Optional |
Intercooler protect cover, warning lamp |
The SINOTRUK HOWO oil tanker truck specification only for your reference, we will recommend other model SINOTRUK oil tanker truck according to your request.
-3. SINOTRUK HOWO Oil Tanker Truck More Information.
-. Tank material: carbon steel, stainless steel, aluminum alloy
-. Tank type: square, oval, round
-. Oil pump: self-priming pump, gear pump, etc.
-. Fuel meter: single-count, double-count, tax-controlled fuel dispenser.
-. Tank truck breathing valve: In order to ensure that the pressure in the tank is basically the same as the atmospheric pressure during the working process of the fuel truck, a breathing valve is installed on the large cover of the tank. The oil level in the tank rises and the pressure increases. When the pressure in the tank is higher than the external pressure 8KPA, the upper valve plate of the breathing valve opens; When the internal pressure is lower than the external pressure 3KPA, the lower valve plate of the breathing valve opens.
