Introduction



The side wall trailer is the most widely used cargo transport trailer in African markets such as Nigeria, Guinea, and Liberia.



The trailer is used for hauling a variety of products and materials, such as sand, gravel, and bulk cargo and is widely employed in the transport industry.



It is particularly well-suited for transporting bagged cement in Nigeria.





What Is A 3 Axles Side Wall Trailer ?



The side wall trailer can be used for transporting both bulk cargo and shipping containers; with a load capacity of up to 60 tons, its versatility makes it highly popular among logistics companies.



Compared to other trailers, TRUCKMAN versions feature:



●High-quality steel

●Branded components

●Customized production



These features enable the trailer to be suitable for various working environments.





Technical Specifications



Description	Parameter Value
Product Name	Brand New 3 Axles 60 Tons Side Wall Trailer
Application	Bulk cargo transport
Axle	3 Axle, 3x16 tons, ZY brand
Tire	315/80R22.5, 12 pcs, TRIANGLE brand
Suspension	Heavy duty suspension
Brake System	WABCO brand
Loading Tons	60,000kg
Overall Dimension	12500x2500x2450mm



How Should A Semi-Trailer Be Maintained?



As an essential tool in road transport, the semi-trailer requires regular care and maintenance. Proper maintenance not only extends the service life of a semi-trailer but also ensures transport safety and enhances operational efficiency.



1.Chassis Maintenance

●Check the bolts and nuts on the chassis.

●Check the lubricant level in the axles.

●Inspect the leaf springs for any fractures or deformation.



After every certain interval of mileage, for instance, approximately every 5,000 kilometers, all visible bolts and nuts on the chassis should be inspected and tightened. Insufficient lubricating oil will accelerate the wear of internal components within the axle. Deformation of the leaf springs can compromise the vehicle's driving stability and comfort; in severe cases, it may even lead to a loss of vehicle control.



2.Tire Maintenance



●Check tire pressure

●Check for tire wear

●Rotate tires periodically



Tire pressure that is too high or too low can affect both the lifespan of your tires and your vehicle's driving performance. You should check your tire pressure regularly using a tire pressure gauge—ideally, at least once a week. Minor damage to a tire can often be repaired, but significant damage requires the tire to be replaced. Additionally, tires should generally be rotated every 10,000 to 15,000 kilometers to ensure more even tread wear.



3.Electrical System Maintenance



●Check the battery charge level

●Check the electrolyte level

●Inspect the electrical wiring



If the voltage is too low, the battery should be charged promptly. At the same time, check the electrolyte level; if it is too low, add distilled water or a specialized battery replenishing fluid. If any damage to the insulation of electrical wires is discovered, wrap the affected areas immediately with insulating tape. Wires that show significant signs of aging should be replaced promptly to prevent short circuits, fires, or other accidents caused by electrical faults.



In summary, the routine maintenance of a trailer encompasses various areas, including the chassis, tires, and electrical systems. Only by diligently carrying out these maintenance tasks can one ensure that the semi-trailer remains in good operating condition, thereby providing a solid foundation for safe and efficient transport.





60 Tons vs 80 Tons Side Wall Trailer Comparison



Model	60 Tons	80 Tons
Fuel Consumption	Lower	Higher
Purchase Cost	Lower	Higher
Load-bearing Capacity	Good	Excellent
Maintenance Cost	Lower	Higher



For most cargo transportation, 60 Tons side wall trailer provides better cost-performance balance.



Transport Efficiency Cost Model (Example):



Assuming:

● Distance: 45 km per trip

● 2 trips per day

● Diesel consumption: 35L/ 100km

● Diesel price: $1.2/L

Estimated daily fuel cost:

=37.8 USD per day

Over one year, optimized route planning can reduce cost by 7-10%.



Export Case



Country: Nigeria

Client Type: Transportation company

Quantity: 1 Unit

Application: Cargo transportation

Feedback:After 15 months of operation, no issues have occurred.

For more information, please visit Brand New 3 Axles 60 Tons Side Wall Trailer To Nigeria



Frequently Asked Questions



Q1: What Is The Price Of a Side Wall Trailer?



Price varies by configuration, carrying capacity and shipping destination. Contact Us for an FOB, CIF, or CFR quotation.



Q2: How Long Does Shipping Take To Africa, Southeast Asia, Or South America?



Standard delivery is 25-35 days.Customized modules may require 35-45 days.



Q3: What Is Mini Quantity For A Order?



Minimum order for one unit.



Q4: Do You Provide After-Sales Service And Spare Parts Support?



Yes, we offer global spare parts supply, technical support.



Q5: How Can We Get The Price Of A Trailer?



Sent us a inquiry on the website or contact us by Whats app and then we will share you a quotation according to your requirement.
