XCMG RP505 Mini Crawler Type Asphalt Paver
XCMG RP505 Mini Crawler Type Asphalt Paver Features
XCMG RP505 has a width of 2m and a length of 5.8m, which is very convenient for the construction work in towns and alleys. At the same time, the machine is equipped with a width-limiting device, with a minimum paving width of 0.8m, which is very suitable for milling "trench" paving work.
XCMG RP505 Mini Crawler Type Asphalt Paver Specification
|
Description |
Parameter Value |
|
Product Name |
XCMG RP505 Mini Crawler Type Asphalt Paver |
|
Application |
Construction works |
|
Engine Power |
86kW |
|
Weight |
12500kg |
|
Brand Name |
XCMG |
|
Basic Paving Width |
1.8m |
|
Max Paving Width |
5m |
|
Max Paving Thickness |
280mm |
|
Hopper Capacity |
12t |
|
Dimension |
5820*2000*3690mm |
XCMG RP505 mini crawler type asphalt paver specification only for your reference, we will recommend other model paver basic your request.
XCMG RP505 Mini Crawler Type Asphalt Paver Advantage
1. Precise and even paving: The machine is equipped with advanced electric control system and paving width automatic control device, the paving width and thickness can be accurately controlled, so that the asphalt is evenly distributed and the paving quality is higher.
2. Comfortable driving and easy operation: The machine adopts humanized design and is equipped with comfortable driver's seat and adjustable manipulator, which makes the driver's operation more simple and comfortable and the maintenance more convenient.
XCMG RP505 Mini Crawler Type Asphalt Paver Detail
The drive of XCMG RP505 is all-hydraulic, equipped with tracked traveling device to strengthen the traction, equipped with 260mm wide split track plate to increase the grounding area, the adhesion becomes higher, and it can be adapted to the construction of various specifications of material trucks. Its hydraulic system adopts load-sensitive control technology, which distributes power according to the size of each functional load, and the power output becomes more efficient and energy-saving.
